EZ1550

EZ1550

Single Input/Output

50A, 3ph, 208V

Network Connectivity
Network Connectivity Dual ports: 1x Gigabit Ethernet (10/100/1000 Mbps) and 1x (10/100 Mbps) connection/IP address
Ethernet Cascading Up to 64 units share a single “daisy-chain” Ethernet connection/IP address
DC Power Sharing Each PDU can provide DC power sufficient to power network management electronics and sensors in a neighboring PDU in the event of AC power source loss
Dual Ethernet Support Dual Ethernet ports for redundant comminication
Dual Network Access Dual network connectivity allows redundancy and Multiple stackholder connectivity for up to 64 units in Ethernet cascading mode
Remote Connectivity HTTP(s), iPV4 and iPV6, Telnet, SSH, Virtual Serial, SNMP (v1, v2c, v3), JSON-RPC, LDAP(S), FTP/SFTP, RADIUS, Redfish DMTF RESTful API
WebUI Interfacce Data efficient REACT framework with native mobile device support
Metering Attributes Voltage(V),Current(A),Apparent Power(kVA),Real Power(kW),Power Factor,Energy(kWH)
Metering Accuracy ± 1% to ISO/IES 62052-21
Management Module Attributes
Microprocessor/Memory Cortex A-5
Field Replacement Hot swap replaceable module; fast plug-and-play connectivity
Module Orientation Tool-less removal and 180⁰ install capable for top or bottom power cord orientation
User Display Dual Displays: large high visibility LED display for key metering information and alarms. Low-power graphical oLED with user controls for local information.
Display Language English, Spanish, German, French, Italian, Korean, Japanese, Chinese (simplified)
Lighted Color Code User programmable color border allows power source identification by PDU
Sensor and Security Support Supports up to 8 digital sensors for environmental sensors and/or electronic locks
